SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 244
Troubleshooting
Refer to P.306.
Refer to P.314.
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
While in monitor mode, check
the outdoor unit and the
function unit concerned.
Connect the service checker.
Press reset and start
operation again.
Is discharge pipe
thermistor property
is normal?(∗1)
NO
YES
Check if temperature of
discharge pipe by using service
checker is the same with actual
measurement value of discharge
pipe thermistor.
NO
·
Discharge pipe thermistor is normal and the
temperature detection of the outdoor unit main PCB is
also normal.
· Actually the temperature of discharge pipe is high.
Replace the discharge pipe
thermistor.
Replace the outdoor unit main PCB
(A1P).
∗1: CHECK 11 Compare the resistance value of discharge pipe thermistor and the value based on
the surface thermometer.
YES
Service Checker
Connect the service checker to compare the
temperature of discharge pipe by using service
checker with actual measurement value of discharge
pipe thermistor (∗1).
Remove the factor of overheat operation.
CHECK 3
CHECK 3
CHECK 11
