SiBE311209 Special Control
Function 112
∗2: The system may be operated beyond the upper limit of frequency of the compressor (in P. 92 and 93) during defrost
operation.
<Function unit>
<Indoor unit>
Actuator
Electric
Symbol
In preparation
In defrosting
operation
After defrosting
operation
Step 1 Step 2
Compressor M1C 0 Hz 0 Hz 210 Hz→52 Hz 0 Hz
Electronic
expansion valve
(Liquid injection)
Y1E 0 pls 0 pls 0 pls 0 pls
Electronic
expansion valve
(Two-stage
selection 1)
Y2E1 200 pls 0 pls 0 pls 200 pls
Electronic
expansion valve
(Two-stage
selection 2)
Y2E2 200 pls 0 pls 0 pls 200 pls
Solenoid valve
(Hot gas)
Y1S OFF ON ON OFF
Solenoid valve
(Two-stage
decompression)
Y2S OFF OFF OFF OFF
Solenoid valve
(Bypass 1)
Y3SONONONON
Solenoid valve
(Bypass 2)
Y4SONONONON
Solenoid valve
(Liquid line
selection)
Y5SONONONON
Ending Conditions 170 sec.
• After
a lapse
of 1 min.
• Pc - Pe
< 0.5MPa
• After a
lapse
of 12 min.
• Tb > 11°C
• After
a lapse
of 1 min.
• Pc - Pe
< 0.5MPa
Part Name Elect. symbol Indoor unit actuator operation during defrost operation
Fan M1F
Thermo. ON unit OFF
Unit not in operation OFF
Thermo. OFF unit OFF
Thermo. ON unit Defrost EV degree
Electronic
expansion valve
Y1E
Unit not in operation 256pls
Thermo. OFF unit Defrost EV degree
OR
OR
OR
