118 2.2 Di Unit <DEC101A51>
Adaptor ED721208
2. Initial setting
z DEC101A51 Switch Settings
Note:
All are set to “OFF” upon shipment from factory.
Name Operation OFF ON
DS2
Abnormal input detection Open/Close
(Concentrated address +4 to 7)
Abnormal input detection method
Open: Close (Normal)
→
Open (Abnormal)
Close: Open (Normal)
→
Close (Abnormal)
Open Close
DS3
Abnormal input detection Open/Close
(Concentrated address +0 to 3)
Open Close
DS4
Buzzer output ON/OFF (Concentrated
address +4 to 7)
ON/OFF switching of buzzer output of
buzzer unit upon detection of failure.
ON OFF
DS5
Buzzer output ON/OFF (Concentrated
address +0 to 3)
ON OFF
DS6-1 Startup failure
Masking time after detecting operation
input.
10 seconds 30 seconds
DS6-2 Failure detection
Recovery method upon detection of
failure.
Automatic
reset
Retained
DS6-3 Monitor input Detection of failure under halting status. Yes No
ON
This indicates the switch knob.
ON
ON
07
D5
04 13
34 7
09 11
Position
08 10
29C
Address No. (low order)
A0
05
E6
06 1201
B8
03 1400 1502
F1
ONON
1-08
Control range DS1
2-00 ~ 2-15
High
order : 1
1-00 ~ 1-15
RS1 Switch Setting Table
<Example>
When Address No.
is set to 1-08
Address No. indicates the
following portion in this case.
Low
order : 8
Control range DS1
setting
RS2
Set Address No. (low order) with the centralized address setting switch (RS1).
Referring to the table below, set the address number low order.
(Address Nos. are 1-00, 1-01, --- 1-15, 2-00, --- 4-15.)
<when a product is
discharged from the factory>
Low
order
DS1
8
When a product is
discharged from the factory
High
order
In this case, it follows
that this equipment uses
Address Nos.
1-08 to 1-15.
(8 numbers max.)
3-00 ~ 3-15
4-00 ~ 4-15
Set the top address of this equipment with the DIII-NET setting switch (DS1/RS1).
Using the DIII-NET setting switch (DS1), set the range of Address No. that is set in this equipment.
Address Nos. 1-00 to 1-15 are factory controlled before shipment.
(high order)
(Address range)
