122 2.3 Dio Unit <DEC102A51>
Adaptor ED721208
K1R
1~200-240V
DEC102A51
CD
D1~4
(Terminal size: M3.5)
K1R
Facility Equipment Operation Circuit Example
Stop
command
D2
CD
D1
DEC102A51 DEC102A51
D4
CD
D3
K4R
1~200-240V
K3R
LOCAL
K3R
Local
stop
Local
operation
K5R
Local
operation
K2R
Output wiring for facility equipment 1
REMOTE
Facility Equipment Operation Circuit Example
K5R
K1R
Facility equipment
protecting device
Facility
equipment
protecting
device
Q1M
S1S
Q1M
S3S
S2S
1~200-240V
Q1M
Local
stop
Operation
command
Stop
command
Operation
command
REMOTE
S2S
Q1M
K2R
Maximum Current
1.5A (Resistive Load)
2A (Resistive Load)
Minimum Current
10mA
10mA
Voltage SPEC
200-240V
DC5~24V
Output SPEC: No-voltage "a" contact
K5R
Output wiring for facility equipment 2
LOCAL
K1R
Facility equipment
protecting device
K5R
K4R
Operation
command
S1S
K5R
S3S
(Terminal size: M3.5) (Terminal size: M3.5)
K2R
K1R
1~200-240V 1~200-240V
Facility
equipment
protecting
device
Operation output
It is possible to select continuous 1 output (4 points) or instantaneous 2 output (ON/OFF pair-2 points).
For switching, refer to 2. Initial Setting
• Wiring at Continuous Output (Up to 4 facility equipments can be connected.)
• Wiring at Instantaneous Output (Up to 2 facility equipments can be connected.)
