2. Insert a USB memory into iTM. Touching the Backup button (1) displays a backup start
EQPƂTOCVKQPFKCNQI
3. 6QWEJVJG;GUDWVVQP#75$OGOQT[EQPVGPVFGNGVKQPEQPƂTOCVKQPFKCNQICRRGCTU
4. Touching the Yes button displays a wait dialog and starts the backup. When backup is complete,
an information dialog appears. Touch the Close button to close the screen and remove the USB
memory.
r #NNVJGHQNFGTUCPFƂNGUKPVJG75$OGOQT[YKNNDGFGNGVGFYJGPVJGDCEMWRDGIKP
r One folder with the following name will be created in the USB memory when the backup
complete.
“Backup_XXXXXXXXXXXX_YYYYMMDD_HHMMSS”
(XXXXXXXXXXXX: MAC address of the iTM, YYYYMMDD_HHMMSS: Year, Month, Day,
Hour, Minute and Second of the backup execution time)
r When backup fails because the USB memory is not inserted or due to an error, an error
dialog appears.
