Installation Manual 3P291714-5
DCM601A53 iTM integrator
13English
1.4 &GVGTOKPKPIKPUVCNNCVKQPRNCEG
Be sure to install the iTM integrator in a place that meets the conditions described in 1.4.1
through 1.4.3 below.
1.4.1 +PUVCNNCVKQPRNCEGCPFOQWPVKPIFKTGEVKQP
Below are the description of the installation place and mounting direction. Be sure to
EQPƂTO
r Installation place: Indoor, free from dust and water splashes
r Mounting direction: Vertical
1.4.2 'PXKTQPOGPVCNEQPFKVKQPU
Make sure that the installation environment meets the following conditions.
r The ambient temperature must be 0 to 40 °C.
r 6JGCODKGPVJWOKFKV[OWUVDG4*QTNGUUYKVJQWVEQPFGPUCVKQP
r There must be no electromagnetic disturbance.
1.4.3 4GSWKTGFURCEG
To install the iTM integrator, the following space is required. Make sure that there is a
minimum clearance of 30 mm from the top edge, 100 mm from the left side edge, 30 mm
from the right side edge, and 60 mm from the bottom edge of the unit.
+PUVCNNCVKQPURCEGTGSWKTGFHQTK6/KPVGITCVQT
Required installa-
tion space
MONITOR MONITOR
MONITOR MONITOR
30mm100mm
290mm
100mm
60mm
60mm
30mm
243mm
A
B
A To p
B Wall
