140
Installation Manual ED721208
Installation Manual 3P291714-1
DCM601A51 intelligent Touch Manager
9English
r Frame bracket
281.4mm
207.7mm
61.6mm
Φ38.5
241mm
224.6mm
224mm
7.5mm
234.4mm
Thickness 1.6mm
r Angle bracket
251.5mm
224mm
112.15mm
211.5mm
28.2mm
20mm
43.7mm
11.6mm
Thickness 1.6mm
