313
ED721208 Commissioning Manual
6
Commissioning Manual (Layout Screen Creation Tool) EM11A024
DCM601A51 intelligent Touch Manager
2
6JG.C[QWV5ETGGP%TGCVKQP6QQNYJKEJKURTQXKFGFCURCTVQHVJG2TGEQPƂIWTCVKQP6QQN5GVCPF
available with the Layout Screen Functionality dealer option, allows you to create layout screens in
CFXCPEG(QTKPHQTOCVKQPQPJQYVQNQIKPVQVJG2TGEQPƂIWTCVKQP6QQN5GVCUYGNNCUVJGFGVCKNGF
description of the tool set, see the appropriate pages of the Commissioning Manual.
You need a separate PC to run the Layout Screen Creation Tool.
See the following table for the hardware and software requirements to run the Layout Screen
Creation Tool:
Function Requirement
PC to run the pre-engineering tool
OS: Windows XP Professional SP3 (32 bit)
Windows VISTA Business SP2 (32 bit)
Windows 7 Professional SP1 (32 bit, 64 bit)
CPU: Intel Core 2 Duo 1.2 GHz or equivalent
RAM: Minimum 2 GB or higher
Free HDD Space: 10 GB or larger
Network: 100BASE-TX or higher network connection
Display Resolution: 1024 × 768 or higher *
Network
100Base-TX
Real transfer rate: 115 kbps or higher
Supported security software
McAfee 2011
Norton 2011
Virus Buster 2011
Flash Player Version 11.1
Web browser
Internet Explorer 8, 9
Firefox 10.0
* When the height of the display resolution is 768 pixels, you should enable the “Auto-Hide the Task Bar”
setting.
Layout Screen Creation Tool
