300
Commissioning Manual ED721208
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
110
Select Basic software and enter the MAC address, Software ID, and User information of the iTM
integrator you want to install.
Write down the activation key that appears on the screen.
3. Powering on data backup battery
To retain the settings even in the event of a power outage, the iTM integrator has a built-in
DCVVGT[$GECWUGVJKUDCVVGT[KUFKUCDNGFD[FGHCWNVVJGƂTUVVJKPI[QWUJQWNFFQKUVQGPCDNGKV
Open the front slide cover and turn the screws to remove the
front slide cover. Set the BACKUP switch to “ON”.
< BACKUP switch >
4. Install the software. For the procedure, see 4-10 Installation.
