328
Commissioning Manual ED721208
17 Commissioning Manual (Layout Screen Creation Tool) EM11A024
DCM601A51 intelligent Touch Manager
Importing the Layout Screen Data
#HVGT[QWJCXGGFKVGFNC[QWVUETGGPFCVCKPVJG2TGEQPƂIWTCVKQP6QQN5GV[QWECPUCXGVJGFCVCQP
a USB memory storage device and import it into iTM unit. To do so, use the following procedures:
For more information on how to save data on a USB memory storage device, see “4-7. Pre-
engineering” in the Commissioning Manual (EM11A021 / EM11A022).
1. Open the Service Settings tab and touch the Layout Setup button to bring up the Layout Setup
window.
(31)
2. Insert the USB memory storage device into the iTM unit and then touch the Layout Screen
Data Input button (31)+ORQTVVJGFCVCD[VQWEJKPIVJG;GUDWVVQPQPVJGEQPƂTOCVKQPFKCNQI
box that appears.
When the data has been imported, iTM restarts automatically.
