66 1.2 Wiring Adaptor for Electrical Appendices (2) <KRP4AA51 / KRP4AA52 / KRP4AA53 / KRP4A54>
Adaptor ED721208
C: 1PA59889L
Wall Mounted Type Floor Standing Type
Concealed Floor Standing Type
Floor Standing Type
Note: Installation box for adaptor PCB is required to install the
adaptor.
Ceiling Mounted Low Silhouette Duct Type
Note: Installation box is necessary for second adaptor.
FAQ71BVV1B
FAY-L
FXA(Q)
Adaptor
(KRP4AA51)
PCB support
(KRP4AA93)
Installation box for adaptor PCB
FXL(Q)
FXN(Q)
Adaptor
(KRP4AA51)
PCB support
Indoor unit PCB
Control box
FAQ100BVV1B
FA(Y)-F(A)
FV(Y)
Adaptor PCB
KRP4AA51
FXYD-KA
PCB Support
