227
ED721208 Commissioning Manual
6
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
22
<Internal Pi>
(15)
(16)
(17)
(18)
(19)
(20)
(15) Port No. VGZVƂGNF Address combo box
Sets up the port number and address to which the management point belongs.
For the port number, touch the Modify button and enter it in the Numerical Input dialog that
appears.
For the address, select it using the combo box.
Duplicated addresses cannot be registered. All addresses must be different.
