1.2 Wiring Adaptor for Electrical Appendices (2) <KRP4AA51 / KRP4AA52 / KRP4AA53 / KRP4A54> 63
ED721208 Adaptor
4
Applied Model
Note:
∗1 FH-NU, FDBG-NU, FDBT-NU and FDMG-PU are not connected.
∗2 Installation box for adaptor PCB is necessary.
1.2.2 Part Names and Functions
Note:
1. This is valid only for the indoor unit, which has a temperature setting function.
2. Terminal No. X18A is for the indoor unit of VRV system. For SkyAir series and other air-conditioner, connect to the
relevant terminal for each units.
Series Applicable
VRV Systems
(VRV Inverter “K(A)” “K(U)” Series and later)
Yes
SkyAir Series ∗1Yes
Room Air-Conditioner No
Packaged Air-Conditioners
FDYB-KA, FDYM-FA, FDY-KA ∗2Yes
FDBG, FDMG, FD No
Other air-conditioners No
Heat Reclaim Ventilator (Note: BRC1C61, 62 etc. are required.) Yes
