153
ED721208 Installation Manual
5
22
Installation Manual 3P291714-1
DCM601A51 intelligent Touch Manager
English
2.6 %QPPGEVKPIK6/RNWUCFCRVQTU
If you have many air conditioners, use iTM plus adaptors to connect them. It is a fact that
the number of indoor groups you can control using a single intelligent Touch Manager is
limited to 64. By using iTM plus adaptors, however, you can connect additional 64 groups
of indoor units per iTM plus adaptor. Moreover, considering that the intelligent Touch Man-
ager can be connected with a maximum of seven iTM plus adaptors, you can control a
total of 512 groups of indoor units at a maximum using a single intelligent Touch Manager.
WARNING
r $GUWTGVQRGTHQTOVJKURTQEGFWTGYKVJVJGRQYGTUWRRN[VWTPGFQHH0QVFQKPI
UQOC[ECWUGCPGNGEVTKEUJQEM
r &QPQVENCORVJGECDNGUYKVJJKIJEWTTGPVNKPGUUWEJCUCRQYGTECDNG
2.6.1 6GTOKPCNUNQECVKQPCPFEQPEGRVWCNEQPPGEVKQPFKCITCO
Connect an iTM plus adaptor to the plus ADP IF terminals located on the rear face. Be
UWTGVQEQPPGEVVJGRQUKVKXGYKTGVJGpqVGTOKPCNCPFVJGPGICVKXGYKTGVQVJGpsqVGTOKPCN
respectively, as these terminals have polarity.
6GTOKPCNUNQECVKQPCPFEQPEGRVWCNEQPPGEVKQPFKCITCO
A KPVGNNKIGPV6QWEJ/CPCIGT4GCTHCEG
B iTM plus adaptor
C RNWU#&2+(KPVGNNKIGPV6QWEJ/CPCIGT
D RNWU#&2+(K6/RNWUCFCRVQT
E iTM plus adaptor on which termination resistor must be enabled
