Daikin RXYQ120PYDN [233/405] Ed721208 commissioning manual
![Daikin RXYQ72PTJU [233/405] Ed721208 commissioning manual](/views2/1708729/page233/bge9.png)
229
ED721208 Commissioning Manual
6
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
24
r Common 2 Tab
Sets up common items 2 for a management point.
Displayed items vary depending on the management point type.
<Outdoor><Indoor>
(22)(22)
(21)
<Internal Pi><D3Chiller, D3Dio, External Dio>
(22)
(21)
(21) Prohibit Manual Operation check box
Select the check box when prohibiting manual operation from the iTM.
(22) Address/ACNSS address VGZVƂGNF
Sets up the ACNSS address.
Touch the Modify button and enter the value in the Numerical Input dialog that appears.
#FFTGUUGUECPDGURGEKƂGFKPUVGRUQHCPFYKVJKPVJGHQNNQYKPITCPIGUQHXCNWGU
Indoor unit: 1 to 128, Outdoor unit: 1 to 127, Internal Pi: 1 to 127
