309
ED721208 Commissioning Manual
6
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
119
6. 9JGPƂPKUJGFVQWEJVJG1-DWVVQPVQENQUGVJGUETGGP
If there is an iTM whose connection status is “Disconnected”, the following Confirm dialog
appears.
To exit setup leaving the iTM disconnected, touch the Yes button. To return to the Controller screen,
touch the No button.
7. Open and close all the Layout Views of iTM.
