![Daikin RXYQ120PYDN [255/405] Displaying the main screen](/img/pdf.png)
Daikin RXYQ120PYDN [255/405] Displaying the main screen
![Daikin RXY8MTLE [255/405] Displaying the main screen](/views2/1708729/page255/bgff.png)
251
ED721208 Commissioning Manual
6
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
46
Download the pre-engineering tool from the Distributor’s Page.
To use the pre-engineering tool, a separate PC is necessary. The requirements for the PC are as
indicated in the table below.
PC requirement for running the pre-engineering tool
Function Requirement
PC to run the
pre-engineering tool
OS: Windows XP Professional SP3 (32 bit)
Windows VISTA Business SP2 (32 bit)
Windows 7 Professional SP1 (32 bit, 64bit)
CPU:
Equivalent to Intel Core 2 Duo 1.2 GHz or
higher
Memory: 2 GB or more
Free HDD space: 10 GB or more
Network: 100Base-TX or higher
Display resolution: 1024 x 768 or higher
Network 100Base-TX
Real transfer rate: 115 kbps or higher
Supported security software
McAfee 2011
Norton 2011
Virus Buster 2011
Flash Player Version 11.1
Web browser Internet Explorer 8, 9
Firefox 10.0
Displaying the main screen
1. Start up the pre-engineering tool on the PC.
