256
Commissioning Manual ED721208
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
51
5. The set up restore data is saved to the USB. Insert the USB memory to iTM to restore. (For
details, see 4-10 Installation)
“Layout Setup data only” is available when the Layout option is enabled and saves only the
Layout Setup data to the USB memory. For the method of entering the Layout Setup data to
the iTM unit, see the supplementary volume Layout View Creation Tool (EM11A024).
NOTE
