ED721208 Commissioning Manual
6
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
113
7. Setting time zone
Set up the local standard time zone you want to use for the system clock.
<Time Zone Settings screen>
1. On the Time Zone Settings screen, select the time zone of your region from the Time Zone
combo box.
2. Touch OK.
6JG6KOG&565GVWRUETGGPCRRGCTU
8. Setting current time and daylight saving time
Adjust the clock and set up the daylight saving time schedule.
<Time/DST Setup screen>
1. 1PVJG6KOG&565GVWRUETGGPUGVWRVJGFCVGVKOGCPFVJGFC[NKIJVUCXKPIVKOGUEJGFWNG
(Enable or disable the daylight saving time function. If enabled, select the start time and the
end time.)
2. Touch OK.
6JG#%#WVQ4GIKUVGTUETGGPCRRGCTU
