304
Commissioning Manual ED721208
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
114
7-2 iTM integrator Service Settings
Set up the iTM integrator unit.
iTM integrator
USB
port
USB memory
Power
(100 240V)
LAN port
Web Remote Management
Router
Web Remote Management
HUB
100Base-TX compliant
iTM iTM iTM iTM iTM
Individually working
as iTM*
5 units connected
Internet
Internet
Service settings described in this chapter are for the iTM integrator unit. Settings for iTM units are
to be made in the respective iTM, or from the iTM integrator Standard View screen by accessing
the respective iTM.
