216
Commissioning Manual ED721208
Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
11
(4) Dealer Option
'PCDNGU&KUCDNGUFGCNGTQRVKQPU
(5) Time Zone
Sets up the difference between the Universal Time Coordinated (UTC) and local time.
(6) History Mgmt. (Delete)
&GNGVGUJKUVQT[TGEQTFUQHCURGEKƂGFRGTKQFHTQOVJGJKUVQT[
(7) Other Setting
'PCDNGU&KUCDNGUVJGp&GVGEV.GXGNqCPFp&T[1RGTCVKQP/QFGq
Detect Level: When enabled, indicates management point error alarms via icons and history.
Dry Operation Mode: When enabled, allows you to set Dry mode from the touch panel, the
Schedule or Interlocking function.
(8) DIII-NET Engineering
Sets up the iTM as Main or Sub. When an upper central controller is also installed, sets Setpoint
Restriction to “Enable” or “Auto”.
6JGp#WVQqQRVKQPCWVQOCVKECNN['PCDNGU&KUCDNGU5GVRQKPV4GUVTKEVKQPFGRGPFKPIQPYJGVJGT
an upper central unit is installed or not.
NOTE
(9) Changeover Option
'PCDNGU&KUCDNGUVJG%JCPIGQXGT1RVKQPHQTCPCKTEQPFKVKQPGT
(10) Layout Setup (Optional function)
Displayed only when Layout View data exists.
#NNQYU[QWVQ'PVGT1WVRWV.C[QWV8KGYFCVC
(11) Contact Info
Sets up contact information (three lines) for inquiries regarding errors in the system and the like.
(12) Outdoor Setup
Allows you to manually register the indoor units that belong to the refrigeration system of each
outdoor unit based on the indoor and outdoor unit’s installation information.
Also, allows you to automatically check leakage for each refrigeration system in a multi-refrigeration
system. You can also make it run at a set time by using the Schedule function.
(13) Energy Navigator (Optional function)
Sets up the reference room temperature, month to start collecting data, and energy conversion type
to be used by the Energy Navigator.
