194
Installation Manual ED721208
8
Installation Manual 3P291714-5
DCM601A53 iTM integrator
English
1.2 7PFGTUVCPFKPIGZVGTPCNFKOGPUKQPU
r iTM integrator body
243mm
151.5mm
207mm
290mm
4.5mm
4.5mm
4.5mm
4.5mm
25mm
25mm
8mm8mm
8mm8mm
256.6mm
272mm
29.5mm
r Wall mounting metal plate
191mm
234.2mm
60mm
40mm
Thickness 0.8mm
