DTC P0222, P0223 TP SENSOR
EC-1031
[HR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
M
A
EC
6. REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace the electric throttle control actuator.
2. Perform EC-857, "
Throttle Valve Closed Position Learning" .
3. Perform EC-858, "
Idle Air Volume Learning" .
>> INSPECTION END
7. CHECK INTERMITTENT INCIDENT
Refer to EC-917, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>> INSPECTION END
Component Inspection
BBS004DI
THROTTLE POSITION SENSOR
1. Reconnect all harness connectors disconnected.
2. Perform EC-857, "
Throttle Valve Closed Position Learning" .
3. Turn ignition switch ON.
4. Set shift lever to D (A/T), 1st (M/T) position.
5. Check voltage between ECM terminals 33 (TP sensor 1 signal),
34 (TP sensor 2 signal) and ground under the following condi-
tions.
6. If NG, replace electric throttle control actuator and go to the next
step.
7. Perform EC-857, "
Throttle Valve Closed Position Learning" .
8. Perform EC-858, "
Idle Air Volume Learning" .
Removal and Installation
BBS004DJ
ELECTRIC THROTTLE CONTROL ACTUATOR
Refer to EM-120, "INTAKE MANIFOLD" .
Terminal Accelerator pedal Voltage
33
(Throttle position sensor 1)
Fully released More than 0.36V
Fully depressed Less than 4.75V
34
(Throttle position sensor 2)
Fully released Less than 4.75V
Fully depressed More than 0.36V
PBIB3038E
