SERVICE DATA AND SPECIFICATIONS (SDS)
EC-1597
[HR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
M
A
EC
SERVICE DATA AND SPECIFICATIONS (SDS) PFP:00030
Fuel Pressure
BBS004T5
Idle Speed and Ignition Timing
BBS004T6
*: Under the following conditions:
Air conditioner switch: OFF
Electric load: OFF (Lights, heater fan & rear window defogger)
Steering wheel: Kept in straight-ahead position
Mass Air Flow Sensor
BBS004T7
*: Engine is warmed up to normal operating temperature and running under no load.
Intake Air Temperature Sensor
BBS004T8
Engine Coolant Temperature Sensor
BBS004T9
Knock Sensor
BBS00587
Heated Oxygen Sensor 1 Heater
BBS004TA
Heated Oxygen sensor 2 Heater
BBS004TB
Crankshaft Position Sensor (POS)
BBS004TC
Refer to EC-1412, "Component Inspection" .
Camshaft Position Sensor (PHASE)
BBS004TD
Refer to EC-1418, "Component Inspection" .
Intake Valve Timing Control Solenoid Valve
BBS00588
Fuel pressure at idle
Approximately 350 kPa (3.5 bar, 3.57 kg/cm
2
, 51 psi)
Target idle speed
A/T No load* (in P or N position) 700 ± 50 rpm
M/T No load* (in Neutral position) 650 ± 50 rpm
Air conditioner: ON
A/T In P or N position 700 rpm or more
M/T In Neutral position 750 rpm or more
Ignition timing
A/T In P or N position
6 ± 5° BTDC
M/T In Neutral position
Supply voltage Battery voltage (11 - 14V)
Output voltage at idle 1.0 - 1.3*V
Temperature °C(°F) Resistance k
25 (77) 1.800 - 2.200
80 (176) 0.283 - 0.359
Temperature °C(°F) Resistance k
20 (68) 2.1 - 2.9
50 (122) 0.68 - 1.00
90 (194) 0.236 - 0.260
Resistance [at 20°C(68°F)] Approximately 530 590k
Resistance [at 25°C(77°F)] 3.4 - 4.4
Resistance [at 25°C(77°F)] 3.4 - 4.4
Resistance [at 20°C(68°F)] 6.7–7.7
