EC-1410
[HR (WITHOUT EURO-OBD)]
DTC P0335 CKP SENSOR (POS)
3. CHECK CKP SENSOR (POS) POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness continuity between CKP sensor (POS) terminal 1 and ECM terminal 75.
Refer to Wiring Diagram.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit
4. CHECK CKP SENSOR (POS) POWER SUPPLY CIRCUIT-III
Check harness for short to power and short to ground, between the following terminals.
OK or NG
OK >> GO TO 5.
NG >> Repair short to ground or short to power in harness or connectors.
5. CHECK COMPONENTS
Check the following.
Accelerator pedal position sensor (Refer to EC-1509, "Component Inspection" .)
Refrigerant pressure sensor (Refer to ATC-85, "Refrigerant Pressure Sensor" .)
OK or NG
OK >> GO TO 10.
NG >> Replace malfunctioning component.
6. CHECK CKP SENSOR (POS) GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness continuity between CKP sensor (POS) terminal 2 and ECM terminal 62.
Refer to Wiring Diagram.
4. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 7.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
7. CHECK CKP SENSOR (POS) INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check harness continuity between CKP sensor (POS) terminal 3 and ECM terminal 61.
Refer to Wiring Diagram.
2. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 8.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
Continuity should exist.
ECM terminal Sensor terminal Reference Wiring Diagram
74 Refrigerant pressure sensor terminal 3 EC-1591, "
Wiring Diagram"
75 Crankshaft position sensor (POS) terminal 1 EC-1407, "Wiring Diagram"
102 APP sensor terminal 5 EC-1503, "Wiring Diagram"
Continuity should exist.
Continuity should exist.
