EC-1646
[K9K]
TROUBLE DIAGNOSIS
12. CHECK ECM
Check the ECM using TEST 6. Refer to EC-1664, "
TEST 6: ECM CHECK" .
>> INSPECTION END
CHART 10: ENGINE JERKING
1. CHECK FUEL
Check that the fuel tank is correctly filled and that the fuel type is suitable.
Isthefueltypesuitableandthetankcorrectlyfilled?
Yes or No
Yes >>GOTO2.
No >> Refill the fuel tank correctly.
2. CHECK LOW PRESSURE CIRCUIT
Check the low pressure circuit using TEST 1. Refer to EC-1660, "
TEST 1: LOW PRESSURE CIRCUIT
CHECK" .
>> GO TO 3.
3. CHECK ENGINE PARAMETERS
Check the engine parameters using TEST 4. Refer to EC-1663, "
TEST 4: PARAMETER CHECK" .
>> GO TO 4.
4. CHECK WIRING HARNESS
Is the engine wiring harness cut off or pinched?
Yes or No
Yes >> Carry out the required repairs.
No >> GO TO 5.
5. CEHCK GLOW PLUG
Check that the glow plugs are working properly.
Is the glow plug resistance above 1?
Yes or No
Yes >> Replace the glow plugs.
No >> GO TO 6.
6. CHECK COMPRESSION PRESSURE
Are the compressions correct?
Yes or No
Yes >>GOTO7.
No >> Carry out the required repairs.
7. CHECK VALVE CLEARANCE
Is the valve clearance properly adjusted?
Yes or No
Yes >>GOTO8.
No >> Make the necessary adjustments.
