TROUBLE DIAGNOSIS
EC-1673
[K9K]
C
D
E
F
G
H
I
J
K
L
M
A
EC
ECM Harness Connector Terminal Layout
BBS0040V
ECM Terminals And Reference Value
BBS0040W
PREPARATION
1. ECM (1) is located in the engine room left side near battery (2).
2. Disconnect ECM harness connectors.
When disconnecting ECM harness connectors, loosen (B) it
with levers (1) as far as they will go as shown in the figure.
ECM (2)
Fasten (A)
3. Connect a break-out box (SST) and Y-cable adapter (SST)
between the ECM and ECM harness connector.
Use extreme care not to touch 2 pins at one time.
Data is for comparison and may not be exact.
MBIB1485E
MBIB1519E
MBIB1518E
