ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-1265
[HR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
M
A
EC
*1: 1st trip DTC No. is the same as DTC No.
*2: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*3: The troubleshooting for this DTC needs CONSULT-II.
*4: When engine is running, MI may flash. For details, refer to EC-1269, "
MI Flashing Without DTC" .
*5: This self-diagnosis is not for ECM power supply circuit, even though “ECM BACK UP/CIRCUIT” is displayed on CONSULT-II screen.
DTC AND 1ST TRIP DTC
The 1st trip DTC (whose number is the same as the DTC number) is displayed for the latest self-diagnostic
result obtained. If the ECM memory was cleared previously, and the 1st trip DTC did not reoccur, the 1st trip
DTC will not be displayed.
If a malfunction is detected during the 1st trip, the 1st trip DTC is stored in the ECM memory. The MI will not
light up (two trip detection logic). If the same malfunction is not detected in the 2nd trip (meeting the required
ECT SEN/CIRC P0118 0118 2 × EC-1361
TP SEN 2/CIRC P0122 0122 1 × EC-1367
TP SEN 2/CIRC P0123 0123 1 × EC-1367
HO2S1 (B1) P0132 0132 2 × EC-1373
HO2S1 (B1) P0134 0134 2 × EC-1381
HO2S2 (B1) P0138 0138 2 × EC-1388
TP SEN 1/CIRC P0222 0222 1 × EC-1395
TP SEN 1/CIRC P0223 0223 1 × EC-1395
KNOCK SEN/CIRC-B1 P0327 0327 2 EC-1401
KNOCK SEN/CIRC-B1 P0328 0328 2 EC-1401
CKP SEN/CIRCUIT P0335 0335 2 × EC-1405
CMP SEN/CIRC-B1 P0340 0340 2 × EC-1413
ECM P0605 0605 1 or 2 × or EC-1420
ECM BACK UP/CIRCUIT
*5
P1065 1065 2 × EC-1423
INT/V TIM V/CIR-B1 P1111 1111 2 × EC-1425
ETC ACTR P1121 1121 1 × EC-1430
ETC FUNCTION/CIRC P1122 1122 1 × EC-1433
ETC MOT PWR P1124 1124 1 × EC-1439
ETC MOT PWR P1126 1126 1 × EC-1439
ETC MOT P1128 1128 1 × EC-1445
TCS/CIRC P1212 1212 2 EC-1450
ENG OVER TEMP P1217 1217 1 × EC-1451
CTP LEARNING P1225 1225 2 EC-1467
CTP LEARNING P1226 1226 2 EC-1469
SENSOR POWER/CIRC P1229 1229 1 × EC-1471
NATS MALFUNCTION P1610 - P1615 1610 - 1615 2 BL-215
P-N POS SW/CIRCUIT P1706 1706 2 × EC-1479
BRAKE SW/CIRCUIT P1805 1805 1 × EC-1487
APP SEN 1/CIRC P2122 2122 1 × EC-1492
APP SEN 1/CIRC P2123 2123 1 × EC-1492
APP SEN 2/CIRC P2127 2127 1 × EC-1501
APP SEN 2/CIRC P2128 2128 1 × EC-1501
TP SENSOR P2135 2135 1 × EC-1511
APP SENSOR P2138 2138 1 × EC-1517
Items
(CONSULT-II screen terms)
DTC*
1
Trip MI
Reference
page
CONSULT-II
ECM*
2
