ON BOARD DIAGNOSTIC (OBD) SYSTEM
ON BOARD DIAGNOSTIC (OBD) SYSTEM
PFP:00028
Introduction
BBS004KM
The ECM has an on board diagnostic system, which detects malfunctions related to engine sensors or actua-
tors. The ECM also records various emission-related diagnostic information including:
The above information can be checked using procedures listed in the table below.
×: Applicable —: Not applicable
*: When DTC and 1st trip DTC simultaneously appear on the display, they cannot be clearly distinguished from each other.
The malfunction indicator (MI) on the instrument panel lights up when the same malfunction is detected in two
consecutive trips (Two trip detection logic), or when the ECM enters fail-safe mode. (Refer to EC-1291, "
Fail-
Safe Chart" .)
Two Trip Detection Logic
BBS004KN
When a malfunction is detected for the first time, 1st trip DTC and 1st trip Freeze Frame data are stored in the
ECM memory. The MI will not light up at this stage. <1st trip>
If the same malfunction is detected again during the next drive, the DTC and Freeze Frame data are stored in
the ECM memory, and the MI lights up. The MI lights up at the same time when the DTC is stored. <2nd trip>
The “trip” in the “Two Trip Detection Logic means a driving mode in which self-diagnosis is performed during
vehicle operation.
When there is an open circuit on MI circuit, the ECM cannot warn the driver by lighting up MI when there is
malfunction on engine control system.
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MI circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MI circuit are detected and demands the
driver to repair the malfunction.
Emission-related Diagnostic Information
BBS004KO
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
×:Applicable —: Not applicable
Emission-related diagnostic information
Diagnostic Trouble Code (DTC)
Freeze Frame data
1st Trip Diagnostic Trouble Code (1st Trip DTC)
1st Trip Freeze Frame data
DTC 1st trip DTC Freeze Frame data
1st trip Freeze Frame
data
CONSULT-II ××× ×
ECM ××*—
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-II screen terms)
DTC*
1
Trip MI
Reference
page
CONSULT-II
ECM*
2
CAN COMM CIRCUIT U1000
1000*
3
2—EC-1344
CAN COMM CIRCUIT U1001
1001*
3
2—EC-1344
CONTROL UNIT(CAN) U1010 1010 2 EC-1347
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.
P0000 0000
Flashing*
4
EC-1269
INT/V TIM CONT-B1 P0011 0011 2 EC-1349
MAF SEN/CIRCUIT P0102 0102 1 × EC-1354
MAF SEN/CIRCUIT P0103 0103 1 × EC-1354
ECT SEN/CIRC P0117 0117 2 × EC-1361
