EC-1312
[HR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
CONSULT-II Function (ENGINE)
BBS004L5
FUNCTION
*: The following emission-related diagnostic information is cleared when the ECM memory is erased.
Diagnostic trouble codes
1st trip diagnostic trouble codes
Freeze frame data
1st trip freeze frame data
ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
Diagnostic test mode Function
Work support
This mode enables a technician to adjust some devices faster and more accurately by following the
indications on the CONSULT-II unit.
Self-diagnostic results
Self-diagnostic results such as 1st trip DTC, DTCs and 1st trip freeze frame data or freeze frame data
can be read and erased quickly.*
Data monitor Input/Output data in the ECM can be read.
Data monitor (SPEC)
Input/Output of the specification for Basic fuel schedule, AFM, A/F feedback control value and the
other data monitor items can be read.
CAN diagnostic support
monitor
The results of transmit/receive diagnosis of CAN communication can be read.
Active test
Diagnostic Test Mode in which CONSULT-II drives some actuators apart from the ECMs and also
shifts some parameters in a specified range.
Function test This mode is used to inform customers when their vehicle condition requires periodic maintenance.
ECM part number ECM part number can be read.
Item
DIAGNOSTIC TEST MODE
WORK
SUPPORT
SELF-DIAGNOSTIC
RESULTS
DATA
MONI-
TOR
DATA
MONI-
TOR
(SPEC)
ACTIVE
TEST
DTC*
1
FREEZE
FRAME
DATA*
2
ENGINE CONTROL COMPONENT PARTS
INPUT
Crankshaft position sensor (POS) ××××
Camshaft position sensor (PHASE) ××××
Mass air flow sensor ×××
Engine coolant temperature sensor ×××××
Heated oxygen sensor 1 ×××
Heated oxygen sensor 2 ×××
Wheel sensor ××××
Accelerator pedal position sensor ×××
Throttle position sensor ×××
Intake air temperature sensor ××××
Knock sensor ×
EPS control unit ××
Refrigerant pressure sensor ××
Closed throttle position switch (accelerator
pedal position sensor signal)
××
Air conditioner switch ××
Park/neutral position (PNP) switch ×××
Stop lamp switch ×××
Battery voltage ××
Load signal ××
