EC-1826
[K9K]
DTC P0606 ECM
DTC P0606 ECM
PFP:23710
Description
BBS0046J
The ECM consists of a microcomputer and connectors for signal
input and output and for power supply. The ECM controls the engine.
On Board Diagnosis Logic
BBS0046K
NOTE:
Special note:
If this DTC is present, the engine speed is set to 1,300 rpm, alouder sound is heard comimg from the
engine and malfunction indiocator (Red) lights up.
When engine is stopped, malfunction indicator (Red) lights up.
Diagnostic Procedure
BBS0046M
1. CHECK DTC
Make sure that which malfunction (DTC second line indication) is displayed.
A, B or C
A >>GOTO2.
B >>GOTO3.
C >>GOTO5.
2. REPLACE ECM
1. Replace ECM.
2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer to BL-218, "
ECM
Re-communicating Function" .
3. Perform Injector Adjustment Value Registration. Refer to EC-1625, "
Injector Adjustment Value Registra-
tion" .
>> INSPECTION END
MBIB1517E
DTC No. Trouble diagnosis name Possible cause
P0606
ECM
1.DEF: Analogue/digital converter
2.DEF: Injection calibration data
3.DEF: Memory self-test
4.DEF: Non refreshed watchdog
5.DEF: Interference on the injector control line
6.DEF: Watachdog activation
ECM
A 1.DEF, 3.DEF, 4.DEF or 6.DEF
B2.DEF
C5.DEF
