DTC P0651 APP SENSOR
EC-1837
[K9K]
C
D
E
F
G
H
I
J
K
L
M
A
EC
DTC P0651 APP SENSOR PFP:22693
Description
BBS004U5
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensors detect the accelera-
tor pedal position and sends a signal to the ECM. The ECM uses the
signal to determine the amount of fuel to be injected.
CONSULT-II Reference Value in Data Monitor Mode
BBS004U6
Specification data are reference values.
On Board Diagnosis Logic
BBS004U7
NOTE:
If DTC P0651 is displayed with DTC P0641, first perform trouble diagnosis for DTC P0641. Refer to
EC-1830, "
DTC P0641 SENSOR POWER SUPPLY" .
Special notes:
If this DTC is present, the engine idle speed is set to 1,000 rpm, the engine performance is reduced, and
Malfunction indicator (Red) lights up.
PBIB1741E
MONITOR ITEM CONDITION SPECIFICATION
PL PTNMR T1 V
Ignition switch: ON
(Engine stopped)
Accelerator pedal: Fully released Approximately 15 %
PL PTNMR T2 V
Ignition switch: ON
(Engine stopped)
Accelerator pedal: Fully released Approximately 6 %
DTC No. Trouble diagnosis name Possible cause
P0651
APP SENSOR 2 CIRCUIT
CO.1: Open circuit or short circuit to +12V
CC.0: Short circuit to ground
Harness or connectors
(The APP sensor 2 circuit is open or shorted.)
Accelerator pedal position sensor
(Accelerator pedal position sensor 2)
