TROUBLE DIAGNOSIS
EC-1675
[K9K]
C
D
E
F
G
H
I
J
K
L
M
A
EC
32 B ECM ground
[Engine is running]
Warm-up condition
Idle speed
Approximately 0V
35 R
Turbocharger boost control
solenoid valve
[Ignition switch ON]
Warm-up condition
Idle speed
0 - 12.5V
[Ignition switch ON]
Warm-up condition
Engine speed: 2,000 rpm
0 - 12.5V
37 B EGR volume control valve
[Engine is running]
Warm-up condition
Idle speed
Approximately 1.1V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
Approximately 0.78V
39 P Fuel pump
[Engine is running]
Warm-up condition
Idle speed
0 - 12.5V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
0 - 12.5V
40 W EGR volume control valve
[Engine is running]
Warm-up condition
Idle speed
Approximately 0.7 - 1.9
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
Approximately 1.5 - 1.9V
41
Sensor ground
(Knock sensor shield circuit)
[Engine is running]
Idle speed
Approximately 0.2V
44 W Knock sensor
[Engine is running]
Idle speed
Approximately 0.3V
TERMI-
NAL
NO.
WIRE
COLOR
ITEM CONDITION
DATA
(DC Voltage and Pulse Signal)
MBIB1504E
MBIB1505E
MBIB1506E
MBIB1507E
