EC-1708
[K9K]
DTC P0016 CKP - CMP CORRELATION
DTC P0016 CKP - CMP CORRELATION
PFP:10328
On Board Diagnosis Logic
BBS0041T
NOTE:
If DTC P0016 is displayed with DTC P0335 or P0340, first perform trouble diagnosis for DTC P0335
or P0340. Refer to EC-1774, "
DTC P0335 CKP SENSOR" or EC-1778, "DTC P0340 CMP SENSOR" .
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present when cranking the engine or at idle speed.
Diagnostic Procedure
BBS0041V
1. CHECK CAMSHAFT POSITION SENSOR
Refer to EC-1783, "
Component Inspection" .
OK or NG
OK >> GO TO 2.
NG >> Replace camshaft position sensor.
2. CHECK SPROCKET
Visually check for chipping signal plate gear tooth.
OK or NG
OK >> GO TO 3.
NG >> Remove debris and clean the signal plate or replace sprocket.
3. CHECK CRANKSHAFT POSITION SENSOR
Refer to EC-1777, "
Component Inspection" .
OK or NG
OK >> GO TO 4.
NG >> Replace crankshaft position sensor.
4. CHECK GEAR TOOTH
Visually check for chipping signal plate gear tooth.
OK or NG
OK >> GO TO 5.
NG >> Replace the signal plate.
5. CHECK TIMING BELT
Refer to EM-272, "
TIMING BELT" .
OK or NG
OK >> GO TO 6.
NG >> Replace timing belt.
DTC No. Trouble diagnosis name Possible cause
P0016
CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELA-
TION
Harness or connectors
(CMP sensor circuit is open or shorted.)
Harness or connectors
(CKP sensor circuit is open or shorted.)
Camshaft position sensor
Crankshaft position sensor
Timing belt
Signal plate
