TROUBLE DIAGNOSIS
EC-1317
[HR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
M
A
EC
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
DATA MONITOR (SPEC) MODE
Monitored Item
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
IDL A/V LEARN
[YET/CMPLT]
Display the condition of idle air volume learn-
ing
YET: Idle Air Volume Learning has not been
performed yet.
CMPLT: Idle Air Volume Learning has already
been performed successfully.
O2SEN HTR DTY
[%]
Indicates the heated oxygen sensor 1 heater
control value computed by the ECM according
to the input signals.
I/P PULLY SPD
[km/h] or [MPH]
×
Indicates the engine speed computed from the
furbine revolution sensor signal.
AC PRESS SEN [V] ×
The signal voltage from the refrigerant pres-
sure sensor is displayed.
Voltage [V]
Voltage, frequency, duty cycle or pulse width
measured by the probe.
Only “#” is displayed if item is
unable to be measured.
Figures with “#”s are temporary
ones. They are the same figures
as an actual piece of data which
was just previously measured.
Frequency
[msec],[Hz]or[%]
DUTY-HI
DUTY-LOW
PLS WIDTH-HI
PLS WIDTH-LOW
Monitored item
[Unit]
ECM
INPUT
SIGNALS
MAIN
SIG-
NALS
Description Remarks
Monitored item [Unit]
ECM
INPUT
SIG-
NALS
MAIN
SIG-
NALS
Description Remarks
ENG SPEED [rpm] ××
Indicates the engine speed computed
from the signal of the crankshaft position
sensor (POS) and camshaft position
sensor (PHASE).
MAS A/F SE-B1 [V] ××
The signal voltage of the mass air flow
sensor specification is displayed.
When engine is running specification
range is indicated.
B/FUEL SCHDL
[msec]
×
“Base fuel schedule” indicates the fuel
injection pulse width programmed into
ECM, prior to any learned on board cor-
rection.
When engine is running specification
range is indicated.
A/F ALPHA-B1 [%] ×
The mean value of the air-fuel ratio feed-
back correction factor per cycle is indi-
cated.
When engine is running specification
range is indicated.
This data also includes the data for the
air-fuel ratio learning control.
