EC-1742
[K9K]
DTC P0200 FUEL INJECTOR
Specification data are reference values and are measured between each terminal and ground.
Pulse signal is measured by CONSULT-II.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
TERMI-
NAL
NO.
WIRE
COLOR
ITEM CONDITION
DATA
(DC Voltage and Pulse Signal)
73
75
77
79
B/P
P/L
G
L
Fuel injector No. 2
Fuel injector No. 4
Fuel injector No. 3
Fuel injector No. 1
[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending on rpm at
idle.
0-9V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
0-9V
74
76
78
80
O
V
R
P
Fuel injector power supply
No. 2
Fuel injector power supply
No. 4
Fuel injector power supply
No. 3
Fuel injector power supply
No. 1
[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending on rpm at
idle.
5 - 10V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
5 - 10V
MBIB1512E
MBIB1513E
MBIB1514E
MBIB1515E
