EC-1740
[K9K]
DTC P0200 FUEL INJECTOR
DTC P0200 FUEL INJECTOR
PFP:16600
Component Description
BBS004UP
The fuel injector is a small, precise solenoid valve. When the ECM supplies a ground to the fuel injector circuit,
the coil in the fuel injector is energized. The energized coil pulls the needle valve back and allows fuel to flow
through the fuel injector into the cylinder. The amount of fuel injected depends upon the injection pulse dura-
tion. Pulse duration is the length of time the fuel injector remains open. The ECM controls the injection pulse
duration based on engine fuel needs.
CONSULT-II Reference Value in Data Monitor Mode
BBS004UQ
Specification data are reference values.
On Board Diagnosis Logic
BBS0043F
NOTE:
If DTC P0200 is displayed with DTC P0201, P0202, P0203, P0204, first perform trouble diagnosis
for other DTC. Refer to EC-1745, "
DTC P0201 - P0204 FUEL INJECTOR" .
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present with engine running.
Special notes:
If this DTC is present, the engine stops.
Malfunction indicator (Red) lights up.
MONITOR ITEM CONDITION SPECIFICATION
FUEL FLOW
Engine: After warming up
Air conditioner switch: OFF
Shift lever: Neutral position
No load
Idle Approximately 4.9 mg/cp
2,000 rpm Approximately 3.5 mg/cp
DTC No. Trouble diagnosis name Possible cause
P0200
FUEL INJECTOR CIRCUIT
CC.0: Short circuit to ground
CC.1: Short circuit to +12V
Harness or connectors
(The fuel injector circuit is shorted.)
Fuel injector
