EC-1680
[K9K]
TROUBLE DIAGNOSIS
Conformity Check
BBS004TH
ECM STATUS AND PARAMETERS
Test Condition: Engine Stopped and Ignition Switch ON
Order Function
Parameter or status
check or action
Display and notes Trouble diagnosis
1 Batteryvoltage PR074: BATTERYVOL 12V<BATTERYVOL<14.4V
In the event of a malfunction,
perform the trouble diagnosis for
CHARGING SYSTEM.
2 Engine speed PR055: ENGINE SPEED
Indicates the engine's rotational
speed in rpm.
In the event of a malfunction,
perform the trouble diagnosis for
DTC P0335 CKP SENSOR.
3
Accelerator pedal
position
PR030:
ACCEL/PDL POS
0%
Indicates the position of the
accelerator pedal as a%.
ACCEL/PDLPOS=0%
In the event of a malfunction,
perform the trouble diagnosis for
APP SENSOR (DTC P0225,
P0651 and P2120) and DTC
P0641 SENSOR POWER SUP-
PLY.
4
Enginr coolant tem-
perature
PR064:
WATER TEMP
Warm: 90°C
Indicates the engine coolant
temperature in °C.
Default value: 80°C
In the event of a malfunction,
perform the trouble diagnosis for
DTC P0115 ETC SENSOR.
5
Fuel tank tempera-
ture
PR063:
FUEL TEMP
Cold = WATER
TEMP
Warm: 50C
Indicates the fuel tank tempera-
ture in °C. This value is given by
the fuel tank temperature sensor.
Default value: 30°C.
In the event of a malfunction,
perform the trouble diagnosis for
DTC P0180 FTT SENSOR.
6 Intake air pressure
PR035: ATOMOS PRESS
Indicates the ambient baromet-
ric pressure in mbar. The sensor
is incorporated in the ECM.
If not consistent, check ATO-
MOS PRESS, INLET PRESS (in
DATA MONITOR mode) and
local ambient barometric pres-
sure, with the engine stopped
and ignition switch ON.
PR032: INLET PRESS
Indicates the pressure in the tur-
bocharger in mbar.
7 Fuel rail pressure PR038:
RAIL PRESSURE
Warm or cold
-90bar<RAIL
PRESSURE > 90
bar
Indicates the fuel rail pressure in
Bar.
This pressure is supplied by the
fuel rail pressure sensor.
Default value: 2000 Bar.
In the event of a malfunction,
perform the trouble diagnosis for
DTC P0190 FRP SENSOR.
8 Engine ET038:
MOTOR
Engine
+ after ignition feed
Indicates the current status of
the engine.
+ after ignition feed
CRANKING
RUNNING
MAINTAINED SUPPLY: Sup-
ply maintained during the
power latch phase.
Stalled: When the engine has
stalled.
PROTECTED: When a level 2
malfunction appears or when
the engine speed is limited to
a certain engine speed.
NONE.
