EC-1274
[HR (WITHOUT EURO-OBD)]
BASIC SERVICE PROCEDURE
6. PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-1279, "
Idle Air Volume Learning" .
Is Idle Air Volume Learning carried out successfully?
Yes or No
Yes >>GOTO7.
No >> 1. Follow the instruction of Idle Air Volume Learning.
2. GO TO 4.
7. CHECK TARGET IDLE SPEED AGAIN
With CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Read idle speed in “DATA MONITOR” mode with CONSULT-II.
Refer to EC-1277, "
IDLE SPEED" .
Without CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed.
Refer to EC-1277, "
IDLE SPEED" .
OK or NG
OK >> GO TO 10.
NG >> GO TO 8.
8. DETECT MALFUNCTIONING PART
Check the Following.
Check camshaft position sensor (PHASE) and circuit. Refer to EC-1413, "DTC P0340 CMP SENSOR
(PHASE)" .
Check crankshaft position sensor (POS) and circuit. Refer to EC-1405, "DTC P0335 CKP SENSOR
(POS)" .
OK or NG
OK >> GO TO 9.
NG >> 1. Repair or replace.
2. GO TO 4.
9. CHECK ECM FUNCTION
1. Substitute another known-good ECM to check ECM function. (ECM may be the cause of an incident, but
this is a rare case.)
2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer to BL-218, "
ECM
Re-communicating Function" .
>> GO TO 4.
A/T: 700 ± 50 rpm (in P or N position)
M/T: 650 ± 50 rpm (in Neutral position)
A/T: 700 ± 50 rpm (in P or N position)
M/T: 650 ± 50 rpm (in Neutral position)
SEF174Y
