EC-1694
[K9K]
TROUBLE DIAGNOSIS
CONSULT-II Reference Value in Data Monitor Mode
BBS0040Z
Remarks:
Specification data are reference values.
Specification data are output/input values which are detected or supplied by the ECM at the connector.
* Specification data may not be directly related to their components signals/values/operations.
7
EGR volume control
valve control position
sensor voltage
PR077: EGR POS SE VO
Indicates the EGR volume
control valve control position
sensor voltage according to
the valve position.
INACTIVE: The valve is not
controlled by the ECM.
ACTIVE: The valve is con-
trolled by the ECM.
0.5V<EGRPOSSEVO<
4.8 V
NONE.
8
Accelerator pedal
position
PR030:
ACCEL/PDL POS
0%
Indicates the percentage of the
pedal position between no
load and full load position
0 < ACCEL/PDL POS < 100%
In the event of a malfunction,
perform the trouble diagnosis for
APP SENSOR (DTC P0225,
P0651 and P2120) and DTC
P0641 SENSOR POWER SUP-
PLY.
9
Engine coolant temper-
ature
PR064:
WATER TEMP
Warm: 90°C
Indicates the engine coolant
temperature in °C.
Default value: 80°C.
In the event of a malfunction,
perform the trouble diagnosis for
DTC P0115 ECT SENSOR.
Order
Parameter or status
check or action
Display and notes Trouble diagnosis
MONITOR ITEM CONDITION SPECIFICATION
ENGINE SPEED
Run engine and compare CONSULT-II value with the tachometer
indication.
Almost the same speed as the
tachometer indication
IDLE REG REF
Engine speed: Idle
Air conditioner switch: OFF
Shift lever: Neutral position
No load
Approximately 800 rpm
ACCEL/PDL POS
Ignition switch: ON
(Engine stopped)
Accelerator pedal: Fully released Approximately 0%
WATER TEMP
Engine: After warming up More than 70°C(158°F)
FUEL TEMP
Engine: After warming up More than 40°C(104°F)
BATTERY VOL
Ignition switch: ON (Engine stopped) 11 - 14V
ATMOS PRESS
Ignition switch: ON
Altitude
Approx. 0m: Approx. 100.62 kPa
(1.0062 bar, 1.026 kg/cm
2
, 14.59 psi)
Approx. 1,000 m: Approx. 88.95 kPa
(0.8895 bar, 0.907 kg/cm
2
, 12.90 psi)
Approx. 1,500 m: Approx. 83.16 kPa
(0.8316 bar, 0.848 kg/cm
2
, 12.06 psi)
Approx. 2,000 m: Approx. 78.36 kPa
(0.7836 bar, 0.799 kg/cm
2
, 11.36 psi)
INLET PRESS
Engine: After warming up
Air conditioner switch: OFF
Shift lever: Neutral position
No load
Idle Approximately 980 mbar
2,000 rpm Approximately 1,010 mbar
AIR FLOW
Engine: After warming up
Air conditioner switch: OFF
Shift lever: Neutral position
No load
Idle Approximately 200 mg/cp
2,000 rpm Approximately 270 mg/cp
