TROUBLE DIAGNOSIS
45 O
Sensor ground
(Knock sensor)
[Engine is running] Approximately 0.3V
47 L
Sensor power supply
(Fuel rail pressure sensor)
[Ignition switch ON] Approximately 5.0V
48 V
Sensor power supply
(Turbocharger boost sensor)
[Ignition switch ON] Approximately 5.0V
49 SB
Sensor power supply
(EGR volume control valve
control position sensor)
[Ignition switch ON] Approximately 5.0V
50 L
Sensor power supply
(Mass air flow sensor)
[Ignition switch ON] Approximately 5.0V
51 R Intake air temperature sensor
[Engine is running]
Warm-up condition
Approximately 0.3 - 5.0V
Output voltage varies with intake
air temperature
53 P
Engine coolant temperature
sensor
[Engine is running]
Warm-up condition
Approximately 0.3 - 5.0V
Output voltage varies with engine
coolant temperature
54 P
Fuel pump temperature sen-
sor
[Engine is running]
Warm-up condition
Approximately 0.3 - 5.0V
Output voltage varies with fuel
pump temperature
55 R Crankshaft position sensor
[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending on
rpm at idle.
0 - 12.5V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
0 - 12.5V
56 Y Camshaft position sensor
[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending on
rpm at idle.
0-1V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm
0-1V
TERMI-
NAL
NO.
WIRE
COLOR
ITEM CONDITION
DATA
(DC Voltage and Pulse Signal)
MBIB1508E
MBIB1509E
MBIB1510E
MBIB1511E
