EC-1582
[HR (WITHOUT EURO-OBD)]
IGNITION SIGNAL
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
TER-
MINAL
NO.
WIRE
COLOR
ITEM CONDITION DATA (DC Voltage)
32 P
ECM relay
(Self shut-off)
[Engine is running]
[Ignition switch: OFF]
For a few seconds after turning ignition
switch OFF
0 - 1.0V
[Ignition switch: OFF]
More than a few seconds after turning igni-
tion switch OFF
BATTERY VOLTAGE
(11 - 14V)
105 G Power supply for ECM [Ignition switch: ON]
BATTERY VOLTAGE
(11 - 14V)
