EC-1322
[HR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
LOAD SIGNAL Ignition switch: ON
Rear window defogger switch: ON
and/or
Lighting switch: 2nd
ON
Rear window defogger switch and
lighting switch: OFF
OFF
IGNITION SW
Ignition switch: ON OFF ON ON OFF ON
HEATER FAN SW
Ignition switch: ON
Heater fan: Operating. ON
Heater fan: Not operating OFF
BRAKE SW
Ignition switch: ON
Brake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
INJ PULSE-B1
Engine: After warming up
Air conditioner switch: OFF
Shift lever: P or N (A/T), Neutral
(M/T)
No load
Idle 2.0 - 3.0 msec
2,000 rpm 1.9 - 2.9 msec
IGN TIMING
Engine: After warming up
Air conditioner switch: OFF
Shift lever: P or N (A/T), Neutral
(M/T)
No load
Idle 1° -11° BTDC
2,000 rpm 25° -45° BTDC
PURG VOL C/V
Engine: After warming up
Air conditioner switch: OFF
Shift lever: P or N (A/T), Neutral
(M/T)
No load
Idle 0%
2,000 rpm 0 - 50%
INT/V TIM (B1)
Engine: After warming up
Air conditioner switch: OFF
Shift lever: P or N (A/T), Neutral
(M/T)
No load
Idle 5° -5°CA
2,500 rpm Approx. 0° -40°CA
INT/V SOL (B1)
Engine: After warming up
Air conditioner switch: OFF
Shift lever: P or N (A/T), Neutral
(M/T)
No load
Idle 0% - 2%
2,500 rpm Approx. 0% - 90%
AIR COND RLY
Engine: After warming up, idle
the engine
Air conditioner switch: OFF OFF
Air conditioner switch: ON
(Compressor operates)
ON
FUEL PUMP RLY
For 1 second after turning ignition switch ON
Engine running or cranking
ON
Except above conditions OFF
THRTL RELAY
Ignition switch: ON ON
COOLING FAN
Engine: After warming up, idle
the engine
Air conditioner switch: OFF
Engine coolant temperature is 94°C
(201°F) or less
OFF
Engine coolant temperature is between
95°C (203°F) and 99°C (210°F)
LOW
*2
Engine coolant temperature is 100°C
(212°F) or more
HIGH
*2
MONITOR ITEM CONDITION SPECIFICATION
