INDEX FOR DTC
EC-1241
[HR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
M
A
EC
Alphabetical Index
BBS004K3
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-1344, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .
If DTC U1010 is displayed with other DTC, first perform the trouble diagnosis for DTC U1010. Refer
to EC-1347, "
DTC U1010 CAN COMMUNICATION" .
Items
(CONSULT-II screen terms)
DTC*
1
Reference page
CONSULT-II
ECM*
2
APP SEN 1/CIRC P2122 2122 EC-1492
APP SEN 1/CIRC P2123 2123 EC-1492
APP SEN 2/CIRC P2127 2127 EC-1501
APP SEN 2/CIRC P2128 2128 EC-1501
APP SENSOR P2138 2138 EC-1517
BRAKE SW/CIRCUIT P1805 1805 EC-1487
CAN COMM CIRCUIT U1000
1000*
3
EC-1344
CAN COMM CIRCUIT U1001
1001*
3
EC-1344
CONTROL UNIT(CAN) U1010 1010 EC-1347
CKP SEN/CIRCUIT P0335 0335 EC-1405
CMP SEN/CIRC-B1 P0340 0340 EC-1413
CTP LEARNING P1225 1225 EC-1467
CTP LEARNING P1226 1226 EC-1469
ECM P0605 0605 EC-1420
ECM BACK UP/CIRCUIT
*5
P1065 1065 EC-1423
ECT SEN/CIRC P0117 0117 EC-1361
ECT SEN/CIRC P0118 0118 EC-1361
ENG OVER TEMP P1217 1217 EC-1451
ETC ACTR P1121 1121 EC-1430
ETC FUNCTION/CIRC P1122 1122 EC-1433
ETC MOT P1128 1128 EC-1445
ETC MOT PWR P1124 1124 EC-1439
ETC MOT PWR P1126 1126 EC-1439
HO2S1 (B1) P0132 0132 EC-1373
HO2S1 (B1) P0134 0134 EC-1381
HO2S2 (B1) P0138 0138 EC-1388
INT/V TIM CONT-B1 P0011 0011 EC-1349
INT/V TIM V/CIR-B1 P1111 1111 EC-1425
KNOCK SEN/CIRC-B1 P0327 0327 EC-1401
KNOCK SEN/CIRC-B1 P0328 0328 EC-1401
MAF SEN/CIRCUIT P0102 0102 EC-1354
MAF SEN/CIRCUIT P0103 0103 EC-1354
NATS MALFUNCTION P1610 - P1615 1610 - 1615 BL-215
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.
No DTC
Flashing*
4
EC-1269
