EC-1636
[K9K]
TROUBLE DIAGNOSIS
6. CHECK ECM POWER SUPPLY AND GROUND CIRCUIT
Connect the CONSULT-II and check the insulation, continuity and absence of interference resistance of the
connections:
ECM terminal 104 and IPDM E/R harness connector terminal 29
ECM terminal 109 and IPDM E/R harness connector terminal 32
ECM terminal 110 and IPDM E/R harness connector terminal 32
ECM terminal 22 and fuse block M7
ECM terminal 25 and ground
ECM terminal 26 and ground
ECM terminal 27 and ground
ECM terminal 32 and ground
ECM terminal 2 and DLC terminal 7
(Refer to EC-1698, "
Wiring Diagram" .)
Repair if necessary.
>> INSPECTION END
CHART 2: THE ENGINE DOES NOT START
1. CHECK FUEL
Check that the fuel reservoir is correctly filled and with the right fuel.
>> GO TO 2.
2. CHECK ENGINE OIL AND ENGINE COOLANT LEVEL
Check the engine oil and coolant levels.
>> GO TO 3.
3. CHECK INLET AIR CIRCUIT
Check the inlet air circuit using TEST 5. Refer to EC-1663, "
TEST 5: AIR INLET CIRCUIT CHECK" .
>> GO TO 4.
4. CHECK CATALYTIC CONVERTER
Is the catalytic converter clogged or deteriorated?
Yes or No
Yes >> Replace the catalytic converter.
No >> GO TO 5.
5. CHECK ELECTRICAL CIRCUIT
Check the electrical circuit using TEST 2. Refer to EC-1661, "
TEST 2: ELECTRICAL CIRCUIT CHECK" .
>> GO TO 6.
