EC-1536
[HR (WITHOUT EURO-OBD)]
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Component Inspection
BBS004RM
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
With CONSULT-II
Check air passage continuity of EVAP canister purge volume control
solenoid valve under the following conditions.
Without CONSULT-II
Check air passage continuity of EVAP canister purge volume control
solenoid valve under the following conditions.
Removal and Installation
BBS004RN
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Refer to EM-120, "INTAKE MANIFOLD" .
Condition
(PURG VOL CONT/V value)
Air passage continuity
between A and B
100% Yes
0% No
PBIA9668J
Condition
Air passage continuity
between A and B
12V direct current supply between termi-
nals 1 and 2
Yes
No supply No
PBIA9560J
