DTC P1121 ELECTRIC THROTTLE CONTROL ACTUATOR
EC-1083
[HR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
M
A
EC
With GST
Follow the procedure “With CONSULT-II” above.
PROCEDURE FOR MALFUNCTION C
With CONSULT-II
1. Turn ignition switch ON and wait at least 1 second.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Set shift lever to D position (A/T), 1st position (M/T) and wait at
least 3 seconds.
4. Set shift lever to P position (A/T), Neutral position (M/T).
5. Start engine and let it idle for 3 seconds.
6. If DTC is detected, go to EC-1083, "
Diagnostic Procedure" .
With GST
Follow the procedure “With CONSULT-II” above.
Diagnostic Procedure
BBS004F9
1. CHECK ELECTRIC THROTTLE CONTROL ACTUATOR VISUALLY
1. Remove the intake air duct.
2. Check if a foreign matter is caught between the throttle valve (1)
and the housing.
: Vehicle front
OK or NG
OK >> GO TO 2.
NG >> Remove the foreign matter and clean the electric throttle
control actuator inside.
2. REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace the electric throttle control actuator.
2. Perform EC-857, "
Throttle Valve Closed Position Learning" .
3. Perform EC-858, "
Idle Air Volume Learning" .
>> INSPECTION END
Removal and Installation
BBS004FA
Refer to EM-120, "INTAKE MANIFOLD" .
SEF058Y
PBIB2974E
