EC-1730
[K9K]
DTC P0115 ECT SENSOR
4. CHECK ENGINE COOLANT TEMPERATURE SENSOR
Refer to EC-1730, "
Component Inspection" .
OK or NG
OK >> GO TO 5.
NG >> Replace engine coolant temperature sensor.
5. CHECK INTERMITTENT INCIDENT
Refer to EC-1697, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>> INSPECTION END
Component Inspection
BBS0042U
ENGINE COOLANT TEMPERATURE SENSOR
1. Check resistance between engine coolant temperature sensor
terminals 2 and 3 as shown in the figure.
2. If NG, replace engine coolant temperature sensor.
Removal and Installation
BBS0042V
ENGINE COOLANT TEMPERATURE SENSOR
Refer to EM-276, "CYLINDER HEAD" .
Engine coolant temperature °C(°F) Resistance k
-40 (-40) 76,000 ± 7,000
-10 (14) 12,500 ± 1,130
25 (77) 2,252 ± 112
50 (122) 810 ± 40
80 (176) 280 ± 8
110 (230) 115 ± 3
120 (248) 88 ± 2
MBIB1488E
