EC-1102
[HR (WITH EURO-OBD)]
DTC P1143 HO2S1
DTC Confirmation Procedure
BBS004FY
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Always perform at a temperature above 10°C(14°F).
Before performing following procedure, confirm that battery voltage is more than 11V at idle.
WITH CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Stop engine and wait at least 10 seconds.
3. Turn ignition switch ON and select “HO2S1 (B1) P1143 of “HO2S1” in “DTC WORK SUPPORT” mode
with CONSULT-II.
4. Touch “START”.
5. Start engine and let it idle for at least 3 minutes.
NOTE:
Never raise engine speed above 3,600 rpm after this step. If
the engine speed limit is exceeded, return to step 5.
6. When the following conditions are met, “TESTING will be dis-
played on the CONSULT-II screen. Maintain the conditions con-
tinuously until “TESTING changes to “COMPLETED”. (It will
take approximately 50 seconds or more.)
If “TESTING” is not displayed after 5 minutes, retry from step 2.
7. Make sure that “OK is displayed after touching “SELF-DIAG
RESULTS”. If “NG” is displayed, refer to EC-1103, "
Diagnostic
Procedure" .
PBIB0546E
ENG SPEED A/T: 1,300 - 2,800 rpm
M/T: 1,500 - 3,600 rpm
VHCL SPEED SE Less than 100 km/h (62 MPH)
B/FUEL SCHDL A/T: 2.8 - 11.2 msec
M/T: 2.0 - 11.2 msec
Shift lever Suitable position
PBIB0547E
SEC769C
