DTC P0235 TC BOOST SENSOR
EC-1763
[K9K]
C
D
E
F
G
H
I
J
K
L
M
A
EC
DTC P0235 TC BOOST SENSOR PFP:22693
Component Description
BBS00446
The turbocharger boost sensor detects pressure in the exit side of
the charge air cooler. The sensor output voltage to the ECM
increases as pressure increases.
CONSULT-II Reference Value in Data Monitor Mode
BBS00447
Specification data are reference values.
On Board Diagnosis Logic
BBS00448
NOTE:
If DTC P0235 is displayed with DTC P0641, first perform the trouble diagnosis for DTC P0641.
Refer to EC-1830, "
DTC P0641 SENSOR POWER SUPPLY" .
Special notes:
Malfunction indicator (Red) lights up.
MBIB1527E
MONITOR ITEM CONDITION SPECIFICATION
INLET PRESS
Engine: After warming up
Air conditioner switch: OFF
Shift lever: Neutral position
No load
Idle Approximately 980 mbar
2,000 rpm Approximately 1,010 mbar
DTC No. Trouble diagnosis name Possible cause
P0235
TURBOCHARGER BOOST SENSOR CIRCUIT
1.DEF: Parmanent low lebel
2.DEF: Parmanent high lebel
3.DEF: Below minimum threshold
4.DEF: Above maximum threshold
5.DEF: Inconsistency
6.DEF: Parmanent at maximum limit
7.DEF: Parmanent at minimum limit
Harness or connectors
(The sensor circuit is open or shorted.)
Turbocharger boost sensor
